19mm PiezoElectric Light Soft Touch Switch

Description Description: TS19C-10EP 19mm piezoelectric light soft touch switch datasheet below: Rating: 3A 250VAC Contact Resistance: 50mΩ max Electrical Life: 50,000 Cycles Function: momentary or latching Dielectric strength: 2,000VAC 1 minute Operating Temperature: -25℃~ 85℃ Insulation Resistance: 1,000mΩ min Panel cutout: 10, 12, 16, 19, 22, 25, 28, 30, 40mm etc. LED voltage: 3V, 6V, 12V, 24V, 48V, 110V, 220V Waterproof Grade: IP40-IP67  Contact Configuration:  Single Pole, Double Pole OEM or ODM: Available   TS19C-10EP
