MYP-25CS – Clear Polyester Splicing & Printed Circuit Board Tape, Silicone Adhesive

MYP-25CS – Clear Polyester Splicing & Printed Circuit Board Tape, Silicone Adhesive Is a 2.5 mil total, 72 yard, 1 mil polyester film with 1.5 mils of electrical grade silicone adhesive.Designed to be fully stable electrically and mechanically at operating temperatures up to 350°F Adhesive is cured to provide maximum resistance to chemicals and leaves no residue during maskingor holding applications. Excellent resistance to abrasives, acids, oils, aging, staining, and water immersion Applications: Splicing silicone coated paper and films Outer wrap on coils, capacitors, motors, and transformers Masking in electroplating, anodizing, and PC boards Physical Properties: Meets UL510 Class B (130ºC / 266ºF) Adhesion to SST: 27 oz/in Tensile Strength: 25 lbs/in Elongation: 100% Dielectric Strength: 5.5 kV Maximum Temperature: -100°F to 350°F 3″ plastic core Alternative to Permacel P-904; Saint Gobain #M52
